Time Tested Stability and Dynamics

The Highlander® prosthetic foot provides active patients with long residual limbs an efficient and smooth gait, with excellent energy return. A split toe provides excellent inversion-eversion, allowing users to walk and run with confidence on uneven terrain. The Highlander® can be used with exoskeletal systems or users weighing up to 500 lbs. As a result, amputees once limited to lower functioning products can now enjoy the benefits provided by a premium energy storage and return device so they can walk farther, faster, longer.

Water-resistant
Engineered for active amputees with long residual limbs
Split toe provides excellent inversion-eversion
Offers ideal blend of stability and action, often preferred by transfemoral amputees
Can be designed for amputees weighing up to 500 lbs.**
Rated to 365 lbs.
36-month warranty

** Highlander® MAX Custom order only

Tech Specs

Item		Highlander®
Weight (27 Cat 4, module with foot shell)		590g
Build Height*	22 - 25cm	3.875” / 98mm
	26 - 28cm	4.25" / 108mm
	29 - 31cm	4.75” / 121mm
Heel rise		3/8” / 10mm

*Build height based on size 27cm Cat 4 foot module with foot shell and 10mm heel rise. Sandal-toe available for sizes 22-28cm.

Module selection according to activity and weight
Weight/ Activity level	100-115lbs 44-52kg	116-130lbs 53-59kg	131-150lbs 60-68kg	151-170lbs 69-77kg	171-195lbs 78-88kg	196-220lbs 89-100kg	221-255lbs 101-116kg	256-285lbs 117-130kg	286-325lbs 131-147kg	326-365lbs 148-166kg	366-420lbs 167-190kg	421-480lbs 191-218kg	481-500lbs 219-227kg
Low	1	1	2	3	4	5	6	7	8	9	10	11	12
Moderate	1	2	3	4	5	6	7	8	9	10	Special Order	Special Order	Special Order
High	2	3	4	5	6	7	8	9	10	11	Special Order	Special Order	Special Order

NOTE: Increasing category numbers indicate increased keel response.

FOR BILATERAL PATIENTS: Increase by one category for added stability.

Documents

Product Sheet

Instructions For Use

L-Codes

L5981
